Astra Hybrid 330

The Astra Hybrid330 is an ultra compact LED hybrid moving head with phenomenal power for its size and delivering a stunning set of visual effects.

Send an enquiry

Description

The Astra Hybrid330 optical system ranges linearly from 3,5° to 52°, and it’s equipped with a large 140mm front lens featuring both an high intensity beam and perfect spotlight, offering a tremendous lumen output and superior evenness compared with other lights in the same category.
The extensive feature set of the Astra Hybrid330 includes functions like aerial effects with a fat and parallel beam and crisp projection textures and pattern effects, with linear CMY, three colour-wheels, an animation wheel, two overlapping prisms, frost and two gobo wheels.

Product Features:

  • Ultra compact hybrid moving light equipped with a 330W LED source
  • Linear zoom ranging from 3,5° to 52°
  • Linear CMY, animation wheel, 2 gobo wheels, 3 colour wheels, 2 overlapping prisms, frost

LIGHT SOURCE

  • Source: 330W high-power white LED
  • CCT: 7.000
  • Luminous flux: (3,5°) 8’158 lm – (52°) 11’684lm
  • Lux: (3,5°) 97’996 lx – (52°) 1’566lx @5 m full
  • Source life expectancy: > 30.000 h

OPTICS

  • Zoom: 3,5° – 52° motorised linear zoom
  • Lens diameter: 140mm / 5.51”
  • Lens type: HD anti-reflection lenses with achromatic coating
  • Focus: motorised

COLOUR SYSTEM

  • Colour mixing: CMY colour system on 3 gradually fading colour wheels
  • CCT: on wheel 2.400 K and 3.200 K
  • Colour wheel: 9 dichroic filters on 3 independent colour wheels
  • Colour wheel: High CRI colour filters

DYNAMIC EFFECTS

  • Control Resolution: 16-bit dimmer
  • Animation wheel: animation wheel with CW and CCW rotation
  • Rotating gobos: 8 rotating gobos + open, interchangeable, indexing
  • Gobo size: outer: 20 mm – image: 16 mm – thickness: up to 3 mm
  • Fixed gobos: 11 fixed gobos + open
  • FX generator: 2 prisms overlap for spectacular aerial effects
  • Circular prism: 8f with bi-directional rotation, indexing
  • Linear prism: 6f with bi-directional rotation, indexing
  • Frost: linear 0 – 100% frost filter

BODY

  • Hardware on-board: sockets for quick-Lock Omega bracket (clamp not included)
  • Pan angle: 540°
  • Tilt angle: 270°
  • Pan/Tilt resolution: bit 8 / 16-bit
  • Feedback: automatic repositioning after accidental movement
  • Body: aluminium structure with high-resistance polycarbonate cover
  • Body colour: RAL 9004

CONTROL

  • Protocols: DMX512, RDM, Art-Net, sACN, W-DMX
  • DMX channels: 29channel
  • Wireless Control: included, LumenRadio Timo Fx DMX/RDM compatible with both CRMX (Lumen Radio) and W-DMX (Wireless DMX)
  • RDM: RDM for remote monitoring and settings
  • Display: LCD high resolution colour display with autoflip
  • Firmware upgrade: yes, via USB – DMX interface (UPBOX2) not included or via USB pen drive
  • Other: Ethernet pass through in case of PSU or Master PCB failure

ELECTRONICS

  • Dimmer: linear 0 ~ 100% mechanical dimmer
  • Dimmer curves: 4 selectable dimming modes available
  • Strobe / shutter: 1 – 30 Hz, electronic
  • Display battery: self-charging battery backup
  • Operating temperature: -10° ~ +45°
  • LED Control: flicker free frequency with adjustable PWM
  • Selectable PWM: 600 ~ 50.000 Hz

ELECTRICAL

  • Mains power supply: 100-240V – 50/60Hz
  • Max power consumption: 517W
  • Output (at 230V): 4 units on a single power line
  • Power factor: > 0,98

PHYSICAL

  • IP rating: 20
  • Cooling: combination of heat pipe cooling system and low noise fan
  • Suspension and fixing: any position with quick-lock omega brackets
  • Pan / tilt lock: for transportation and maintenance
  • Signal connection: Amphenol XLR 5p IN/OUT connectors
  • Data connection: Neutrik Art-Net RJ45 IN/OUT
  • Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
  • Dimensions (WxHxD): 411x638x244mm / 16.18”x25.12”x9.61”
  • Weight: 21,6kg / 47.62lbs

CERTIFICATIONS / APPROVALS

  • Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC

BOX CONTENT

  • 1 x ASTRAHYB330
  • 2 x OS24
  • User manual
  • 1 x 1,5 meters power cable (BARE END – NEUTRIK POWERCON TRUE1 IP65)


MUSMOV303 Astra Hybrid 330 Datasheet.pdf    506.76 KB
MUSMOV303 Astra Hybrid 330 Manual.pdf    6.7 MB
