LED Colour Ranger (27) Architectural

Categories: , , , SKU: LEDWSH272 Tag:

The LED Fusion wash 27 Architectural is an outdoor rated IP66 RGBW wash light.

Send an enquiry

Description

LED Colour Ranger (27) features:

  • – IP66-rated wash light
    – Advanced thermal (fanless) design
    – 27 x 10W RGBW LEDs deliver 12K lumens of perfectly blended colour
    – 3 zone independent control of horizontal sections
    – Silent operation suitable for indoor studio as well as outdoor use
    – Selectable LED modulation for flicker-free output from 600Hz ~ 25kHz
    – Ultra-linear dimming technology for flawless color mixing
    – Indestructible diecast body and tempered glass front panel
    – Virtual colour wheel and white presets from 2800 ~ 10000K
    – Four selectable dimmer curve modes
    – Available optics/filters: 15°, 25°, 45°
    – RDM, DMX and W-DMX wireless control
Photometrics
Lamp Source 27 x 10W RGBW LEDs
Beam Angle 15° (with included filter)
Field Angle 28° (with included filter)
Output 12000 lm
Key Features
Tilt angle +/- 90°(manual)
Colour Mixing RGBW
Strobe 0-30 Hz
Dimming 4 dimming curve modes
Control
Protocol RDM, DMX and W-DMX
DMX Channels 4 / 6 / 10 / 12
Display OLED function menu with 4 touch buttons
Power
Mains 100V-240VAC,  50/60 Hz
Consumption 268W
Power connections PowerCon true IP65 In/Out
Data connections IP66 XLR In/Out
Power Linking up to 7 units @230V / up to 3 units @120V
Housing
Material Diecast aluminum, tempered glass
Finish Matte black
IP rating IP65
Thermal
Cooling Passive (fanless)
Physical
Dimensions 454 x 153 x 269 mm
Weight 9 KG


ek lights@colour ranger architectural 27.xml    37.39 KB
EK_Lights@Colour_Ranger_Architectural_27@1.00.gdtf    44.27 KB
LEDWSH272 ColourRanger27A Manual.pdf    712.93 KB
LEDWSH272 LED COLOUR RANGER 27 Datasheet.pdf    1.65 MB
