Description
Thanks to its wide 8°- 48° zoom, Scenius is perfect for every use. A modern focus tracking system concentrates maximum luminous efficiency precisely on the effect you wish to project, and the focus may be set to be fully automatic.
With Scenius you have a light in your hands whose white light and color reproduction fidelity will completely amaze you. The fixture produces a 6500 K output color temperature that does not vary over time; also, Scenius can count on a very high CRI, which is extremely unusual for a metal halide light source. The colors cover a broad spectrum, even including pastel shades, thanks to a CMY system, a 7-color wheel and a linear CTO filter.
The special effects are of course top-ranking: 2 rotating gobo wheels, each with 6 interchangeable gobos, a rotating prism and an interchangeable graphics wheel for spectacular new effects, a highly precise iris. The fixture can also be used in wash mode by inserting a new design of frost filter. It can be run at 1400W or in energy saving mode at 1200W.
- 1400W OSRAM discharge lamp
- 8°-48° zoom
- Focus tracking system
- 6500 K output color temperature
- Very high CRI
- CMY System + Linear CTO
- 7-colour wheel
- 2 Wheels with 6+6 rotating Gobos
- Rotating Prism
- Interchangeable Graphics Wheel
- 16 blades fast Iris
- Variable “soft edge” frost
- Variable flood frost
- Very precise 0-100% dimmer
- Fast stop/strobe effect
- Light can be run at 1400W or 1200W
- Art-Net / RDM
- Quiet, reliable and road-ready
- Weight: 38 Kg
POWER SUPPLIES
AC power input Neutrik PowerCON TRUE1 (IP65)
200-240V 50/60 Hz
INPUT POWER
1800 VA
LIGHT SOURCE
OSRAM Lok-it! HTI 1400/PS Lamp
– Color Temperature: 6.000 K
– Life: 750 hrs
– Very high CRI
– Luminoux flux: 120000 lm
– Base PGJ28 Lok-it!
– Light can be run at 1400W or 1200W in Energy Saving mode
OPTICS
Zoom 8° – 48°
ø142 mm front lens
Electronic Focusing
COLOUR SYSTEM
CMY System
Linear CTO
Colour Wheel with 7 colour filters
EFFECTS SECTION
Two wheels with 6+6 rotating gobos (image ø26 mm)
Interchangeable Graphics Wheel
Optional 8-fixed gobo wheel (interchangeable with the Graphics Wheel)
Rotating Prism with 4 faces
16 blades fast Iris
Variable “soft edge” frost
Variable flood frost
Very precise 0-100% dimmer
Fast stop/strobe effect
CONTROL AND PROGRAMMING
32 or 36 DMX 512 control channels
DMX protocol signal: USITT DMX 512
Art-Net / RDM
Display: LCD 128 x 64 dots, backlit LED, white on black
Pan and Tilt Resolution: 16 bit
Focus Indexing Resolution: 16 bit
Dimmer Resolution: 16 bit
Rotation gobo Resolution: 16 bit
Movement control: vectorial
DMX signal connection: 5 pole XLR input and output
Software upload through DMX input / Ethernet input
BODY
Aluminum and steel structure with plastic covers
Two side handles for transportation
Device locking PAN and TILT mechanisms for transportation and maintenance
MOVING BODY
PAN
Angle Rotation: 540°
Fast speed: 4.210” sec
Normal Speed: 4.958” sec
Resolution TILT: 2.10938°
Resolution TILT FINE: 0.00824°
Accuracy:
Resolution ± 0.2 (Range 0.4°)
TILT
Angle Rotation: 268°
Fast speed: 2.536” sec
Normal Speed: 3.246” sec
Resolution TILT: 1.04688°
Resolution TILT FINE: 0.00409°
Accuracy:
Resolution ± 0.2° (Range 0.4°)
ELECTRONICS
Long life self-charging buffer battery
ON/OFF lamp control from the lighting desk
Function reset from the lighting desk
“AUTOTEST” function from menu ARTNET
Electronic monitoring with status error
Cooling system monitoring
DMX level monitoring on all channels
Internal data transmission diagnostics
Firmware Upgrade with no power
Firmware upload from another fixture
SAFETY DEVICES
Bipolar circuit breaker with thermal protection
Automatic break in power supply in case of overheating
Forced ventilation with fans and heat sink.
WORKING POSITION
Working in any position
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
CE MARKING
In conformity with the European Directives:
• 2014/35/EU – Safety of electrical equipment supplied at low voltage (LVD)
• 2014/30/EU – Electromagnetic Compatibility (EMC)
• 2011/65/EU – Restriction of the use of certain hazardous substances (RoHS)
• 2009/125/EC – EcoDesign requirements for Energy-related Products (ErP)
WEIGHT
38 kg (83.6 lbs)
