Description
Highly efficient and impressive light output. Suitable for permanent architectural installations and for temporary events. High brightness LEDs RGBW/FC, combines an innovative optic system with a wide beam and a superb colour mixing.
SINGLE 40 RGBW/FC
Refined and compact, IP67, the new SINGLE 40 RGBW/FC (Full Color) is a LED Lighting fixture with a large and uniform light output.
Send an enquiry• SOURCE
n. 40 RGBW (16W) LEDs
280W total light power
Total lm: R 3000, G 6000, B 925, White 6750
• OPTIC
25º (45mm lenses)
On request:
– 10º, 40º (45 mm lenses)
– 65° plan-filter
– Barn-door
– Anti-glare
• TILT
Manual 160°
• CONTROL
Standard interface: RS-485, optocoupled input
Protocol: USITT DMX512
• CONNECTIONS
Signal: 4pin IP 67 connector (male-female)
Main Power: 3x1mm cable 1,5mt.
Available as accessories:
– Wireless DMX receiver
• SETUP AND CONFIGURATION
Control panel with touch technology
Led display with flip function
Dedicated DMX channel for white balance
DMX or Auto mode with Master-Slave function
Intelligent temperature control
Flicker-free function
Smooth dimming function
Halogen simulation
CYM simulation
• RATING PROTECTION
IP 67
• DMX CHANNELS
– 9CH mode
– 5CH mode
– 4CH mode
• POWER SUPPLY
Voltage range: 88-264VAC, 124-370VDC
Frequency range: 47-63Hz
Active Power factor: PF>0.95/230VAC, PF>0.98/115VAC
Current: 1A@230VAC; Fuse T5A
Power: 250W (on white balance)
• PHYSICAL
WxDxH: 613x185x415 mm
Weight: 19 Kg.
